SDH8322S features various protections, including VDD undervoltage protection, VDD overvoltage protection, lead edge blanking, over current protection, over temperature protection, etc. Meanwhile, if any protection occurs, the circuit will continue to restart automatically until the system recovers.
Adjustable output voltage including: 12V, 15V and 18V
High-voltage self-startup
Burst mode at light load
Frequency reduction
Soft startup
VDD undervoltage protection
VDD overvoltage protection
Leading edge blanking
Over current protection
Over temperature protection
Product Name | Package form | Marking | Hazardous Substance Control | Packing Type | Remarks |
---|---|---|---|---|---|
SDH8322STR | SOP-8-225-1.27 | SDH8322S | Halogen free | Tape & Reel | |
SDH8322S | SOP-8-225-1.27 | SDH8322S | Halogen free | Tube |
title | Types of | Size (KB) | date | Download the latest English version |
---|---|---|---|---|
SDH8322S | 0 | 1970-01-01 | SDH8322S Brief Datssheet |
