The SLP74LV1T08 is a single, level translating 2-input AND gate.
The input is designed with a lower threshold circuit to match 1.8 V input logic at VCC= 3.3V and can be used in 1.8V to 3.3V level up translation. In addition, the 5V tolerant input pins enable level down translation (3.3V to 2.5V output at VCC = 2.5V).
The output level is referenced to the supply voltage and supports 1.8V, 2.5V, 3.3V and 5.0V CMOS levels. The wide VCC range of 1.6V to 5.5V allows generation of desired output levels to connect to controllers or processors.
Logic output is referenced to VCC
1.2V to 1.8V at VCC = 1.8V
1.5V to 2.5V at VCC = 2.5V
1.8V to 3.3V at VCC= 3.3V
3.3V to 5.0V at VCC = 5.0V
3.3V to 1.8V at VCC= 1.8V
3.3V to 2.5V at VCC= 2.5V
5.0V to 3.3V at VCC= 3.3V
Specified from -40°C to +85°C and from -40°C to +125°C
Product Name | Package form | Marking | Hazardous Substance Control | Packing Type | Remarks |
---|---|---|---|---|---|
SLP74LV1T08KMTR | SOT-353-5L | ST | Halogen free | Tape & Reel |
Fig.1 Function diagram
Fig.2 Logic diagram
