SAP072B
DUAL OPERATIONAL AMPLIFIERS
The SAP072B consist of two independent, high-voltage JFET-input, frequency-compensated operational amplifiers designed to operate from a single power supply over a wide range of voltages. Operation from split supplies also is possible if the difference between the two supplies is 10V to 30V.The devices feature high slew rates, low-input bias and offset currents, and low offset-voltage temperature coefficient.
Main feature
- Wide Single−Supply Range: 10V~30V
- Wide Common-Mode and Differential Voltage Ranges
- Low Input Bias and Offset Currents
- High-Input Impedance: JFET Input Stage
- Common-Mode Input Voltage Range Includes VCC+
- Internal Frequency Compensation
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SAP072BSA |
SOP-8-225-1.27 |
SAP072B |
Halogen free |
Tube |
|
SAP072BSATR |
SOP-8-225-1.27 |
SAP072B |
Halogen free |
Tape&Reel |
|
Documents
title |
Types of |
Size (KB) |
date |
Download the latest English version |
SAP072B |
|
0 |
1970-01-01 |
SAP072B Datasheet |
