SDH790XSCN
NON-ISOLATED LED LIGHTING DRIVE IC WITH BUILT-IN HIGH-VOLTAGE MOSFET, HIGH PFC AND HIGH CONSTANT CURRENT ACCURACY
SDH790XSCN is designed for non-isolated LED driving with built-in high voltage power MOSFET and high voltage JFET. With this structure, MOSFET current is sensed and closed-loop is formed with the internal error amplifier for high constant current accuracy and high input/output regulation rate. Also, high PF in full range is available due to its own PFC control. Boundary Conduction mode is adopted for decreasing switching loss and improving the conversion efficiency. SDH790XSCN can realize high power factor without any external integral capacitor. Peripheral VCC pin and VCC capacitor (to GND) are unnecessary. SDH790XSCN integrates various protections, such as output open circuit protection, output short circuit protection, cycle-by-cycle over current protection, and over temperature protection. SDH790XSCN has ultra low start-up current and operating current, is able to high effectively drive highlight LED in full voltage input range.
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SDH7901SCN |
SOP-7-225-1.27 |
/ |
Halogen free |
Tube |
|
SDH7901SCNTR |
SOP-7-225-1.27 |
/ |
Halogen free |
Tape & Reel |
|
SDH7902SCN |
SOP-7-225-1.27 |
/ |
Halogen free |
Tube |
|
SDH7902SCNTR |
SOP-7-225-1.27 |
/ |
Halogen free |
Tape & Reel |
|
SDH7903SCN |
SOP-7-225-1.27 |
/ |
Halogen free |
Tube |
|
SDH7903SCNTR |
SOP-7-225-1.27 |
/ |
Halogen free |
Tape & Reel |
|
SDH7904ASCN |
SOP-7-225-1.27 |
/ |
Halogen free |
Tube |
|
SDH7904ASCNTR |
SOP-7-225-1.27 |
/ |
Halogen free |
Tape & Reel |
|
SDH7904SCN |
SOP-7-225-1.27 |
/ |
Halogen free |
Tube |
|
SDH7904SCNTR |
SOP-7-225-1.27 |
/ |
Halogen free |
Tape & Reel |
|
