SLP74HC245
OCTAL BUS TRANSCEIVER WITH 3-STATE OUTPUTS
The SLP74HC245 is an 8-bit transceiver with 3-state outputs. The device features an output enable (OE) and send/receive (DIR) for direction control. A HIGH on OE causes the outputs to assume a high-impedance OFF-state. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Main feature
- Wide Operating Voltage Range of 2 V to 6 V
- Octal bidirectional bus interface
- Input levels with CMOS levels
- Non-inverting 3-state outputs
- ESD protection:
- Specified from -40C to +85C and -40°C to +125°C
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SLP74HC245SNTR |
SOP-20-375-1.27 |
74HC245 |
Halogen free |
Tape & Reel |
|
SLP74HC245JTTR |
TSSOP-20-225-0.65 |
74HC245 |
Halogen free |
Tape & Reel |
|
