SLP74HCT14
HEX SCHMITT-TRIGGER INVERTERS
The SLP74HCT14 is a high-speed Si-gate CMOS device.The SLP74HCT14 contains six independent inverters. Each circuit functions as an independent inverter. Because of the Schmitt-Trigger action, the inverters are capable of transforming slowly changing input signals into sharply defined, jitter-free output signals.
Main feature
- All inputs have Schmitt-trigger actions
- TTL level input
- ESD protection:
- Latch-up performance: 100mA
- Specified from -40°C to +85°C and from -40°C to +125°C
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SLP74HCT14JY |
TSSOP-14-225-0.65 |
74HCT14 |
Halogen free |
Tube |
|
SLP74HCT14JYTR |
TSSOP-14-225-0.65 |
74HCT14 |
Halogen free |
Tape & Reel |
|
SLP74HCT14SB |
SOP-14-225-1.27 |
74HCT14 |
Halogen free |
Tube |
|
SLP74HCT14SBTR |
SOP-14-225-1.27 |
74HCT14 |
Halogen free |
Tape & Reel |
|
