SD20M60AC8
600V/20A 3-PHASE FULL-BRIDGE DRIVER (INTELLIGENT POWER MODULE)
SD20M60AC8 is a 3-phase brushless DC motor driver with high integration and high reliability for medium power inverter driving such as air condition, dishwasher, and industrial sewing machine. It has embedded six low-loss IGBT and three high-speed half-bridge gate drivers with high voltage. The under voltage, short circuit and over temperature protections integrated make the circuit work safely in a wide range. The current of each phase can be detected separately because there is one independent negative DC terminal for each phase. SD20M60AC8 uses high-insulation design, compact package and carries heat easily, which makes it easy to use especially for compact installation applications.
Main feature
- Built-in six low-loss 600V/20A IGBT;
- Built-in high-voltage gate driver;
- Built-in under voltage, over temperature and over current protections;
- Built-in bootstrap diode;
- Compatible with 3.3V, 5V MCU interface, active high;
- Three independent negative DC terminal for inverter current detection;
- Alarm signal: for low-side under voltage and short circuit protections;
- Package in DBC design with low thermal resistance;
- Insulation level: 2500Vrms/min
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SD20M60AC8 |
DIP-27H |
SD20M60AC8 |
Halogen free |
Tube |
|
