SD8525L
FAST TURN-OFF SYNCHRONOUS RECTIFIER CONTROLLER
SD8525L is a high-performance, fast turn-off synchronous rectifier controller with a built-in 60V MOSFET. It replaces diode rectifiers for high efficiency in high-performance isolated power supply topology application. It can work with the flyback controller in CCM, DCM, QR modes. SD8525L can be powered by the high-voltage winding or the output voltage in the flyback converter applications. A slew rate detection circuit prevents the SD8525L from turning on falsely during resonance operation. The SD8525L is available in SOP8 package.
Main feature
- Integrated high-performance MOSFET (60V, 10mΩ)
- Supports both high-side and low-side synchronous rectification applications
- Supports DCM, CCM, and QR operations
- Slew rate detection prevents false turn-on during resonance operation
- Powered by the high-voltage winding or the output voltage
- 250μA standby current
- SOP8 package
Ordering Information
Product Name |
Package form |
Marking |
Hazardous Substance Control |
Packing Type |
Remarks |
SD8525L |
SOP-8-225-1.27 |
SD8525L |
Halogen free |
Tube |
|
SD8525LTR |
SOP-8-225-1.27 |
SD8525L |
Halogen free |
Tape&Reel |
|
